EURO II Vehicle Engine 4DX series

مشاركة:
Model4DX12-964DX22-1104DX22-120
Type4-cylinder in-line, direct injection, water cooling, turbocharged
Bore×Stroke (mm)100×100 102×118
Valves/cylinder2
Displacement (L)3.1423.857
Rated power70.68188
Rated speed (r/min)3200
Net power/speed (kW/r/min)687986
Maximum torque (Nm)245324343
Maximum torque speed (r/min)2000 ~ 2200 1800-2000
Fuel consumption (g/kW·h)225
Smoke (m-1)≤ 3.0
Noise dB(A)≤ 95.5
Emission Compliant (TAS)EURO Ⅱ
Net Mass (kg)380
Length×Width×Height (mm)810×700×850


Model4DX13-964DX13-1044DX23-1104DX23-1204DX23-130






Type4-cylinder in-line, direct injection, water cooling, turbocharged inter-cooled
Bore×Stroke (mm)100×100 102×118
Valves/cylinder2
Displacement (L)3.1423.857
Rated power70.676.5818895.5
Rated speed (r/min)30002800
Net power/speed (kW/r/min)6874788592
Maximum torque (Nm)260285324343380
Maximum torque speed (r/min)1900~2100 1800~ 2100
Fuel consumption (g/kW·h)225
Smoke (m-1)≤ 3.0
Noise dB(A)≤ 95.5
Emission Compliant (TAS)EURO Ⅱ
Net Mass (kg)380
Length×Width×Height (mm)810×700×850
